High-Pressure Refrigerant Reclaim Unit
Engineered for high-volume, precision purification cycles. This mobile platform processes complex chemical mixtures down to pristine standards in a single automated operational pass.
- Compatible Gases: R-12, R-22, R-134a, R-500, R-502
- Purification: Single-pass execution meeting ARI 700 benchmarks
- Processing Throughput: 5 lbs / minute
- Electrical Configuration: 240V Power Requirements
- Mobility: Heavy-duty integrated chassis for fast deployment
Low-Pressure Refrigerant Reclaim Unit
A specialized, high-capacity chemical separation platform designed to clean low-pressure systems safely without necessitating external chilled water infrastructure.
- Compatible Gases: R-11, R-113, R-123, R-114, R-141
- Purification Tier: Single-pass processing exceeding ARI 700 rules
- Internal Vessel: 2,500 lb capacity (3,500 lb & 5,000 lb hulls available)
- Processing Throughput: 5 lbs / minute
- Electrical Configuration: 240V Operation
- Cooling Setup: On-board condensing unit (Chilled water not required)
R-290 Flammable Hydrocarbon Reclaim System
An explicitly engineered, explosion-proof processing skid built to navigate the unique challenges of volatile hydrocarbon alternative refrigerants safely.
- Safety Compliance: Class 1, Division 2, Group D Environmental Rating
- Purification Matrix: Single-pass refining matching ARI 700 parameters
- Reclaim Processing Rate: 12 lbs / minute
- Liquid Bulk Transfer: Up to 300 lbs / minute
High-Pressure Chiller Pump-Down System
An all-in-one maintenance asset constructed to simultaneously handle bulk refrigerant transfers and deep system evacuations during mechanical teardowns.
- Compatible Gases: R-12, R-22, R-134a, R-114
- Available Containment Vessels: 1,600 lb / 2,400 lb / 3,400 lb layouts
- Filtration Capacity: Active extraction removes cross-linked oils, acids, and moisture
- Operational Modes: Dedicated Recovery, Recycle, and Reclaim cycles
- Reclaim Throughput: 3 lbs / minute
- Electrical Configuration: 110V Convenience Power
Low-Pressure Chiller Pump-Down System
Tailored specifically to handle the extraction parameters of low-pressure centrifugal equipment configurations while scrubbing field contaminants out of the inventory.
- Compatible Gases: R-11, R-113, R-123
- Available Containment Vessels: 1,600 lb / 2,400 lb / 3,400 lb layouts
- Integrated Protection: Internal separators isolate sludge, moisture, and acid tracks
- Operational Modes: Multi-tier Recovery, Recycle, and Reclaim tracking
- Reclaim Throughput: 3 lbs / minute
- Electrical Configuration: 110V Standard Utility Line
High-Volume Rapid Field Recovery System
An absolute workhorse designed for maximum raw recovery speed on large mechanical networks, featuring a multi-port intake structure for parallel machine scavenging.
- Pressure Tier Capacity: Dual-rated for all High and Low-Pressure Gases
- Compressor Assembly: Industrial 5 HP open-drive compressor core
- Vapor Extraction Speed: 10 to 14 lbs / minute
- Liquid Extraction Speed: 75 to 90 lbs / minute
- Manifold Assembly: Five separate 1/2" inlet connections for simultaneous machinery attachment
- Electrical Configuration: 208/230V Plant Input
- Performance Control: Integrated digital amp meter to safely trim peak field rates
- Condensation Matrix: Air-cooled radiator framework (Chilled water/refrigerated loops optional)
Mobile Field Recovery Unit
A compact, agile recovery platform balanced onto an ergonomic dolly layout, perfect for accessing tight mechanical spaces without sacrificing open-drive processing dependability.
- Pressure Tier Capacity: Universally rated for High and Low-pressure compounds
- Compressor Assembly: 1.5 HP open-drive compressor
- Vapor Extraction Speed: 1 lb / minute
- Liquid Extraction Speed: 26 to 30 lbs / minute
- Connection Configuration: 3/8" high-flow fittings
- Electrical Configuration: 110V Convenience Wall Power
- Condenser Profile: High-efficiency air-cooled fan assembly
Advanced Molecular Sieve Dehydration Tower
Eliminates the repetitive expense and downtime of replacing disposable core filter driers during high-volume plant processing operations.
- Moisture Abatement: Drives deep dehydration thresholds to < 10 ppm
- Thermal Rejuvenation: Built-in internal heating grid to dry and cycle sieve material indefinitely
- Pressure Metrics: 250 psig working limit (400 psig structural upgrade available)
- Electrical Configuration: 230V / 9 Amp Power Track
- Batch Capacity: Specially sized to maintain dry streams on massive 10,000 lb chemical runs
